DockerCompose部署ElasticSearch集群+Kibana+Logstash

安装ES

1、修改宿主机参数

sysctl -w vm.max_map_count=262144

2、创建目录并授权

#创建es目录
mkdir /home/elasticsearch

#创建es节点挂载目录
for port in `seq 1 3`; do \
  mkdir -p elastic0${port}/data; \
  mkdir -p elastic0${port}/conf \
  &&  envsubst <elasticsearch.yml> elastic0${port}/conf/elasticsearch.yml ;\
  mkdir -p elastic0${port}/logs; \
  mkdir -p cert; \
 done

 #授权elastic用户对 elasticsearch 目录的操作权限
 chown -R elastic:elastic elasticsearch/

3、编写docker-compose文件

version: "3"

networks:
  es:
    driver: bridge

services:
  elastic01:
    image: elasticsearch:7.17.2
    container_name: elastic01
    restart: always
    volumes:
      - /home/elasticsearch/elastic01/data:/usr/share/elasticsearch/data
      - /home/elasticsearch/elastic01/conf/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml
      - /home/elasticsearch/elastic01/logs:/user/share/elasticsearch/logs
      - /home/elasticsearch/cert/elastic-certificates.p12:/usr/share/elasticsearch/config/elastic-certificates.p12
    ulimits:
      memlock:
        soft: -1
        hard: -1
    ports:
      - "9201:9200"
      - "9301:9300"
    environment: # 设置环境变量,相当于docker run命令中的-e
      - node.name=elastic01
      - cluster.name=es-docker-cluster
      - discovery.seed_hosts=elastic02,elastic03
      - cluster.initial_master_nodes=elastic01,elastic02,elastic03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms512m -Xmx512m"
    networks:
      - es


  elastic02:
    image: elasticsearch:7.17.2
    container_name: elastic02
    restart: always
    volumes:
      - /home/elasticsearch/elastic02/data:/usr/share/elasticsearch/data
      - /home/elasticsearch/elastic02/conf/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml
      - /home/elasticsearch/elastic02/logs:/user/share/elasticsearch/logs
      - /home/elasticsearch/cert/elastic-certificates.p12:/usr/share/elasticsearch/config/elastic-certificates.p12
    ulimits:
      memlock:
        soft: -1
        hard: -1
    ports:
      - "9202:9200"
      - "9302:9300"
    environment: # 设置环境变量,相当于docker run命令中的-e
      - node.name=elastic02
      - cluster.name=es-docker-cluster
      - discovery.seed_hosts=elastic01,elastic03
      - cluster.initial_master_nodes=elastic01,elastic02,elastic03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms512m -Xmx512m"
    networks:
      - es


  elastic03:
    image: elasticsearch:7.17.2
    container_name: elastic03
    restart: always
    volumes:
      - /home/elasticsearch/elastic03/data:/usr/share/elasticsearch/data
      - /home/elasticsearch/elastic03/conf/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml
      - /home/elasticsearch/elastic03/logs:/user/share/elasticsearch/logs
      - /home/elasticsearch/cert/elastic-certificates.p12:/usr/share/elasticsearch/config/elastic-certificates.p12
    ulimits:
      memlock:
        soft: -1
        hard: -1
    ports:
      - "9203:9200"
      - "9303:9300"
    environment: # 设置环境变量,相当于docker run命令中的-e
      - node.name=elastic03
      - cluster.name=es-docker-cluster
      - discovery.seed_hosts=elastic01,elastic02
      - cluster.initial_master_nodes=elastic01,elastic02,elastic03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms512m -Xmx512m"
    networks:
      - es

3、配置elasticsearch.yml

network.host: 0.0.0.0
xpack.security.enabled: true
xpack.security.transport.ssl.enabled: true
xpack.security.transport.ssl.verification_mode: certificate
xpack.security.transport.ssl.keystore.path: /usr/share/elasticsearch/config/elastic-certificates.p12
xpack.security.transport.ssl.truststore.path: /usr/share/elasticsearch/config/elastic-certificates.p12

4、生成证书

先启动一个容器，进入容器后生成证书后将证书拷贝出来供集群使用。

启动容器

docker run -dit --name=tmpes elasticsearch:7.17.2 /bin/bash

进入容器

docker exec -it tmpes bash

生成elastic-stack-ca.p12，

./bin/elasticsearch-certutil ca

然后生成 elastic-certificates.p12 ，

./bin/elasticsearch-certutil cert --ca elastic-stack-ca.p12

两条命令均一路回车即可，不需要给秘钥再添加密码

生成证书后退出容器，然后将elastic-certificates.p12 拷贝到宿主机。之后“工具”容器tmpes任由你处置。

docker cp tmpes:/usr/share/elasticsearch/elastic-certificates.p12 /home/elasticsearch/cert

到此准备工作已完成。

5、启动es集群

docker-compose up -d

然后另外打开一个ssh窗口设置集群密码：

docker exec -it elastic01 /bin/bash

ES中内置了几个管理其他集成组件的账号即：apm_system, beats_system, elastic, kibana, logstash_system, remote_monitoring_user，使用之前，首先需要添加一下密码

interactive：给用户一一设置密码。
auto：自动生成密码。

root@fd7635ffd8c9:/usr/share/elasticsearch/bin# elasticsearch-setup-passwords interactive
Initiating the setup of passwords for reserved users elastic,apm_system,kibana,kibana_system,logstash_system,beats_system,remote_monitoring_user.
You will be prompted to enter passwords as the process progresses.
Please confirm that you would like to continue [y/N]y


Enter password for [elastic]:
Reenter password for [elastic]:
Enter password for [apm_system]:
Reenter password for [apm_system]:
Enter password for [kibana_system]:
Reenter password for [kibana_system]:
Enter password for [logstash_system]:
Reenter password for [logstash_system]:
Enter password for [beats_system]:
Reenter password for [beats_system]:
Enter password for [remote_monitoring_user]:
Reenter password for [remote_monitoring_user]:
Changed password for user [apm_system]
Changed password for user [kibana_system]
Changed password for user [kibana]
Changed password for user [logstash_system]
Changed password for user [beats_system]
Changed password for user [remote_monitoring_user]
Changed password for user [elastic]
root@fd7635ffd8c9:/usr/share/elasticsearch/bin#

配置完毕之后，可以通过如下方式访问es服务：

http://10.18.63.109:9202/_cluster/health?pretty

6、问题解决：

问题1

如果出现该问题则表示宿主机data挂载目录没有权限

Likely root cause: java.nio.file.AccessDeniedException: /usr/share/elasticsearch/data/nodes

[root@uids elasticsearch]# chmod 777 /home/elasticsearch/elastic01/data/
[root@uids elasticsearch]# chmod 777 /home/elasticsearch/elastic02/data/
[root@uids elasticsearch]# chmod 777 /home/elasticsearch/elastic03/data/

安装kibana

docker-compose

kibana:
    image: kibana:7.17.2
    container_name: kibana-uids
    environment:
      SERVER_NAME: kibana
      ELASTICSEARCH_URL: http://elastic01:9200  #这里填容器内部的服务名和端口
      XPACK_MONITORING_ENABLED: true
    ports:
      - 5601:5601
    depends_on:
      - elastic01
    volumes:
      - /home/kibana/kibana.yml:/usr/share/kibana/config/kibana.yml
    networks:
      - es

kibana.yml

server.port: 5601
server.name: "kibana-uids"
server.host: "0"
server.publicBaseUrl: "http://10.18.63.109:5601/"
elasticsearch.username: "elastic"
elasticsearch.password: "uids#@876"
elasticsearch.hosts: ["http://elastic01:9200"]
monitoring.ui.container.elasticsearch.enabled: true
i18n.locale: "zh-CN"

启动

docker-compose up -d

安装logstash

1、docker-compose

logstash:
    image: logstash:7.17.2
    container_name: logstash-uids
    restart: always
    ports:
      - "4560:4560"
      - "9600:9600"
    environment:
      LS_JAVA_OPTS: "-Xmx1g -Xms1g"
    depends_on:
      - elastic01
    volumes:
      - /home/logstash/pipeline:/usr/share/logstash/pipeline
      - /home/logstash/logstash.yml:/usr/share/logstash/config/logstash.yml
    networks:
      - es

安装logstash时可能会出现容器内挂载的文件不会同步到宿主机目录下，需要手动配置有如下文件：

2、所需文件

jvm.options

## JVM configuration

# Xms represents the initial size of total heap space
# Xmx represents the maximum size of total heap space

-Xms1g
-Xmx1g

################################################################
## Expert settings
################################################################
##
## All settings below this section are considered
## expert settings. Don't tamper with them unless
## you understand what you are doing
##
################################################################

## GC configuration
-XX:+UseConcMarkSweepGC
-XX:CMSInitiatingOccupancyFraction=75
-XX:+UseCMSInitiatingOccupancyOnly

## Locale
# Set the locale language
#-Duser.language=en

# Set the locale country
#-Duser.country=US

# Set the locale variant, if any
#-Duser.variant=

## basic

# set the I/O temp directory
#-Djava.io.tmpdir=$HOME

# set to headless, just in case
-Djava.awt.headless=true

# ensure UTF-8 encoding by default (e.g. filenames)
-Dfile.encoding=UTF-8

# use our provided JNA always versus the system one
#-Djna.nosys=true

# Turn on JRuby invokedynamic
-Djruby.compile.invokedynamic=true
# Force Compilation
-Djruby.jit.threshold=0
# Make sure joni regexp interruptability is enabled
-Djruby.regexp.interruptible=true

## heap dumps

# generate a heap dump when an allocation from the Java heap fails
# heap dumps are created in the working directory of the JVM
-XX:+HeapDumpOnOutOfMemoryError

# specify an alternative path for heap dumps
# ensure the directory exists and has sufficient space
#-XX:HeapDumpPath=${LOGSTASH_HOME}/heapdump.hprof

## GC logging
#-XX:+PrintGCDetails
#-XX:+PrintGCTimeStamps
#-XX:+PrintGCDateStamps
#-XX:+PrintClassHistogram
#-XX:+PrintTenuringDistribution
#-XX:+PrintGCApplicationStoppedTime

# log GC status to a file with time stamps
# ensure the directory exists
#-Xloggc:${LS_GC_LOG_FILE}

# Entropy source for randomness
-Djava.security.egd=file:/dev/urandom

# Copy the logging context from parent threads to children
-Dlog4j2.isThreadContextMapInheritable=true

logstash.yml

xpack.monitoring.enabled: true
xpack.monitoring.elasticsearch.username: elastic
xpack.monitoring.elasticsearch.password: uids#@876
http.host: "0.0.0.0"
xpack.monitoring.elasticsearch.hosts: [ "http://elastic01:9200" ] #host和端口填写容器内部对应的服务名和端口

pipelines.yml

- pipeline.id: micro-service-log
  path.config: "./pipeline/uids-service-es.conf"  #该地址填写管道地址，一个管道对应一个id和一个配置

安装Metricbeat

kibana7.17.2版本堆栈监测需要安装Metricbeat

拉取metricbeat镜像

docker pull docker.elastic.co/beats/metricbeat:7.17.2

创建metricbeat文件夹

mkdir metricbeat

配置metricbeat.yml

metricbeat.config:
  modules:
    path: ${path.config}/modules.d/*.yml
    # Reload module configs as they change:
    reload.enabled: false

metricbeat.autodiscover:
  providers:
    - type: docker
      hints.enabled: true

metricbeat.modules:
- module: docker
  metricsets:
    - "container"
    - "cpu"
    - "diskio"
    - "healthcheck"
    - "info"
    #- "image"
    - "memory"
    - "network"
  hosts: ["unix:///var/run/docker.sock"]
  period: 10s
  enabled: true

processors:
  - add_cloud_metadata: ~

output.elasticsearch:
  hosts: ["elastic01:9200"]
  username: 'elastic'
  password: 'uids#@876'

启动容器

docker run -d \
  --name=metricbeat \
  --user=root \
  --volume="$(pwd)/metricbeat.docker.yml:/usr/share/metricbeat/metricbeat.yml:ro" \
  --volume="/var/run/docker.sock:/var/run/docker.sock:ro" \
  --volume="/sys/fs/cgroup:/hostfs/sys/fs/cgroup:ro" \
  --volume="/proc:/hostfs/proc:ro" \
  --volume="/:/hostfs:ro" \
  -net=elasticsearch_es
  docker.elastic.co/beats/metricbeat:7.17.2

metricbeat 配置集成kibana、 elasticsearch

进入容器:

docker exec  -it metricbeat bash

启动 system 和容器监控 modules:

metricbeat modules enable system
metricbeat modules enable docker
